The ability to place stops at exact XY locations on your table makes setting up rectangular and irregular shapes a snap.
- Eliminates the need to probe or edge-find workpieces.
 |
 |
|
| Once the spindle is in the desired location, the Locating Pin is placed under the stop locator tool. | The spring-loaded handle is pulled down and a hole in the plastic pin is lined up with the point on the tool.
Vacuum is applied to the stop, fixing its location directly below the spindle. |
Locating holes on all BLICK Suction Cups. |
| Part Number | 19-102-11 |
| Tool Height | 119.312 mm (4.697 in.) |
| Extension Height | 33.020 mm (1.300 in.) |
| Total Extended Height | 152.332 mm (5.997 in.) |
*This new and improved Stop Locator Tool. It is more accurate at full extension than the previous version of the Stop Locator Tool.
NOTE: Customer must supply 1/2″ gas tool holder.
Downloads
Stop Locator Tool
$335.00
