Available in ANY height and most popular fitting sizes.

IMPORTANT: Use provided 6 mm alan wrench to avoid overtightening. Overtightening will cause damage to the clamp.

Part Number 13-102-01
Mounting Method Mechanical Screw (8 mm)
Clamping Area 32 mm Depth x 38 mm Width
(1.25″ x 1.5″)
Material Thickness 1.4~4 cm (.55″~1.57″)
Base Surface Area 59 in2
Base Dimensions 150 x 300 mm (5.91″ x 11.81″)
Bottom Seal Part # 13-102-02-11

* More jaw heights are available upon request.
